Sold 12m x 30m Hoecker P12 Marquee - East Yorkshire

Description

30m x12m Hoecker P12 Marquee

Sold as a complete unit, everything you will need to erect except pvc, in great condition but requires new pvc
Span Width: 11870mm
Eave Height: 2400mm
Ridge Height: 4580mm
Roof Pitch: 20°
Longest Component: 6377mm (Rafter with insert)
Aluminium Profile: 48mm x 110mm 4 track
Aluminium Spec: Anodised, Extruded, Tempered, 6082
Wind Speed Rating: 60mph, 27 m/s, 97km/h
Snow Loading: 0.2kn m2 Not including internal hanging loads
Purlin Profile: 60mm x 60mm
Steel Spec: Hot Dip Galvanised Steel Inserts
Bay Spacing: 3m
Frame Bracing: Roof Wires with Diagonal Bar or Portal Brace
Ground Fixing: 850mm Stakes, Anchor Bolts, Weights
Maximum suspended weight per span: 85kg from a single point or 170kg if spread evenly across the span from two points.
Structural Calculations: BS EN 1999 Eurocode 9
BS EN 1991-1-4:200+A1:2010 [wind]
BS EN 13782:2015


Delivery notes

We can deliver and erect if required at a small extra cost, or collection from HU12 8FB
fr

This item is now sold


Price: Sold
